Charging Management for Administrations

Frontalansicht ecoChargingCoach von ecocoach AG

ecoChargingCoach – the Charging Management

Are you looking for an intelligent charging management system? The charging management system from ecocoach AG is the ideal solution. It controls the electrical power when operating several charging stations and guarantees the fastest possible charging of all vehicles.

Der ecoChargingCoach ist mit folgenden Herstellern kompatibel

Perfectly tailored to your administrative needs

Effizient das Elektroauto laden mit dem Lademanagement-System, dem ecoChargingCoach, von ecocoach AG

Future-proof and technology-open charging control

Start from pole position for future requirements in the field of electromobility. The ecoChargingCoach is an open-technology solution ready for current and future legal requirements and innovative mobility concepts.

Energieflüsse werden mit dem ecoEnergyCoach von ecocoach AG überwacht und gesteuert

Save on grid connection and electricity costs in the long term

Save costs by fully utilising your current connection capacity. Take into account photovoltaic power and consumption peaks.

Inbetriebnahme und Parametrierung mit dem ecoSetupTool von ecocoach AG

Measure, display and bill consumption

Monitor your charging park online and bill customers or rental car parks individually for their charging current. Use your existing management software to import data or leave everything to a certified billing service provider.

ARRANGE A CONSULTATION NOW

Customized charging concepts

You can count on our expertise. Your customized concept optimally addresses the mobility profiles and requirements of building owners, guests, employees and tenants.

This means you know precisely what infrastructure you need and at what level of expansion. We show you how to integrate charging stations into your building, taking into account the grid infrastructure and load profile, whether in combination with PV systems, electricity storage systems, or billing systems. You gain planning security and cost transparency thanks to a separate project budget. Operation is also simplified: even before installation, you have maintenance and periodic billing information. So, it's clear that everything starts with a coherent concept.

Technical data ecoChargingCoach

Case	500x500x210mm
Connections	Modbus TCP Modbus UDP Ethernet switch, 6 ports
Measuring transformer connections for transformer measurement of	House connection point Photovoltaic system
Functions	Charge management Power connection monitoring Export of consumption data in CSV format Licensing/software subscriptions Future connection to third-party backend billing system
Monitoring of	Consumption of the charging stations Energy flows in buildings Production of the photovoltaic system
Integration of	Controllable charging stations Non-regulatable charging stations
Compatibility	ABB, Alfen, Heidelberg, KEBA, Mennekes, Wallbe, Weidmüller, others available on request
Optional interfaces	Modbus RTU / RS485 Ethernet switch, 8 ports Digital input, 8 channel
Instrument transformer connections for transformer measurements of	Electromobility sub-distribution
Optional interfaces energy management	Floating contact / SG Ready, 2-channel 0-10 V signal (analogue output) PT 1000 input, 4-channel Digital output 24 V DC, 8-channel Digital input, 8-channel M-Bus; rated current: max. 40 standard loads with 1.5mA each
Interfaces for billing systems via APO & OCPP	egonline (CH) swisscharge.ch (CH) eCarUp (CH) chargecloud (D, CH, EU) Plugsurfing (D, EU) Implementation of further interfaces possible on request
Certification	ISO 50001 Energy Management Ready

technical data sheet

WE ARE HAPPY TO ADVISE YOU

Get your charging infrastructure concept now!

Mobility needs are individual, as is the right charging infrastructure. The ecoChargingCoach, therefore, starts with a customized concept. This includes a situation and needs analysis, recommendations for procurement and installation, and information on operation and maintenance.

contact now

Seitenansicht ecoChargingCoach von ecocoach AG

Are you interested in an on-site product demo?

Then contact us today to arrange an appointment with an ecocoach specialist.

FAQs - Frequently asked questions

As the ecoChargingCoach is manufacturer-independent, the charging point can be switched on or off using the ecocoach app on a smartphone.

ecocoach provides charging management and ensures that external billing service providers can bill in parallel via OCPP (Open Charge Point Protocol) (in accordance with the technical data sheet).

It is also possible to export the list of expenses per user via ecoOneClick. This allows the various cost centres to be billed.

The ecoChargingCoach is compatible with the charging stations of the manufacturers listed on the compatibility list, including ABB, Heidelberg, Weidmüller, and many more.

It is recommended that a dynamic charging management system be used for two or more charging stations to ideally distribute the available charging power to the charging points. This is the only way to ensure simultaneous charging.

A lack of charging management can lead to the power not being optimally distributed and overloading the fuse.

No, the ecoChargingCoach does not require any maintenance. The installer provides first-level support.

No, there are no ongoing costs for charging management. However, depending on the billing solution, third-party providers may incur additional costs.

Our reference customers and reference projects make the future of energy tangible

Charging management

The REAL association of municipalities operates the largest electric refuse collection fleet in Central Switzerland with a focus on efficient charging and load management for a prioritised supply mandate.
